3ton Front-end Wheel Loader
3 ton front-end wheel loader can be applied on mining,quarries and aggregates,heavy infrastructure,road construction and so on.The transmission we used is Beilian transmission or Hangzhou Advance transmission.Both of them have hydraulic power shift and after equipped with transmission,our 3 ton front-end wheel loader is much easier to operate and also high efficiency.After years of market validation,these two kinds of transmissions which are popular among clients from different countries,are good quality and have a long service life.The whole frame is enhanced so that the machine is stronger and also can be able to work for a very long time and to accomplish tasks in a dangerous and harsh environment.Here is the specification.
| Performance | Loader lifting capacity | 3000KG |
| Operating weight | 10000KG | |
| Rated bucket capacity | 1.8m³ | |
| Max. tractive force | 97KN | |
| Max. breakout force | 127KN | |
| Max. grade ability | 30° | |
| Max. dump height | 3100mm | |
| Max. dump reach | 1130mm | |
| Overall dimension(L×W×H) | 7180×2350×3230mm | |
| Min. turning radius | 6250mm | |
| Engine | Model | Weichai |
| Type | Inline, water-cooled, four stroke | |
| Cylinder-Inner diameter×stroke | 6-108×130mm | |
| Rated power | 92KW | |
Maximum torque | 500N.m | |
Min fuel-consumption ratio | ≤213g/kw.h | |
Transmission system | Torque converter | YJ320B-1 |
Gearbox mode | Powershift engaged straight gear | |
Gear shift | 4 forward shift and 2 reverse shift | |
Maximum speed | 38km/h | |
| Drive axles | Wheel base | 2758mm |
Wheel tread | 1800mm | |
Ground clearance | 400mm | |
| Hydraulic system | System working pressure | 16Mpa |
| Boom lifting time | 4.83s | |
| Total time | 9.15±0.5s | |
| Fuel tank capacity | 170L | |
| Self-levelling bucket | yes | |
| Brake system | Service brake | Air assist disc brake on 4 wheels |
| Parking brake | Manual brake | |
| Tire | Tire specification | 17.5-25 |
Front tire pressure | 0.4Mpa | |
Rear tire pressure | 0.35Mpa |
