3ton Front Loader

Name: China 3ton Front Loader Manufacturers, Factory - Low Price - SHANMON
Brand: SHANMON
SKU: 154227532

3 ton front loader is designed for utilities,building,agriculture,forestry and so on.Our 3 ton front loader is equipped with Tie 2 Weichai engine which fits well with our machine.

Send Inquiry

3 ton front loader is designed for utilities,building,agriculture,forestry and so on.Our 3 ton front loader is equipped with Tie 2 Weichai engine which fits well with our machine.The engine hood and large radiator are designed behind the cabin with two large openings on them respectively so that the operator can have much more space to check and maintenance the engine and other parts.The cabin is included two curved arc windshield which give the operator better view to finish the tasks and also the air conditioner and good sealing provide the operator a better driving environment.Here is the specification.

Performance	Loader lifting capacity	3000KG
	Operating weight	10000KG
	Rated bucket capacity	1.8m³
	Max. tractive force	97KN
	Max. breakout force	127KN
	Max. grade ability	30°
	Max. dump height	3100mm
	Max. dump reach	1130mm
	Overall dimension(L×W×H)	7180×2350×3230mm
	Min. turning radius	6250mm
Engine	Model	Weichai
	Type	Inline, water-cooled, four stroke
	Cylinder-Inner diameter×stroke	6-108×130mm
	Rated power	92KW
	Maximum torque	500N.m
	Min fuel-consumption ratio	≤213g/kw.h
Transmission system	Torque converter	YJ320B-1
	Gearbox mode	Powershift engaged straight gear
	Gear shift	4 forward shift and 2 reverse shift
	Maximum speed	38km/h
Drive axles	Wheel base	2758mm
	Wheel tread	1800mm
	Ground clearance	400mm
Hydraulic system	System working pressure	16Mpa
	Boom lifting time	4.83s
	Total time	9.15±0.5s
	Fuel tank capacity	170L
	Self-levelling bucket	yes
Brake system	Service brake	Air assist disc brake on 4 wheels
Brake system	Parking brake	Manual brake
Tire	Tire specification	17.5-25
	Front tire pressure	0.4Mpa
	Rear tire pressure	0.35Mpa
